TOP FEATURES |
||
 |
||
|
|
|
|
| FOLDING BRAKE & CLUTCH LEVERS | CHROMOLY STEEL FRAME & ALUMINUM SWINGARM | KENDA® TIRES | 161 CC ENGINE |
|
*
|
||
|
||
| ENGINE | ||
| Engine Type | YX™, Single Cylinder, 4 Stroke, Air / Oil Cooled | |
| Displacement | 161 cc | |
| Bore x Stroke | 60 mm x 57 mm | |
| Rated Output | 13.25 hp @ 8,500 rpm | |
| Fuel Supply | Mikuni® Carburetor, 26 mm | |
| Ignition | CDI | |
| Starter | Kick | |
| Transmission | 4-up Manual | |
| CHASSIS | ||
| Front Suspension | Rebound / Compression Adjustable Forks, Inverted; 8 inches Travel | |
| Rear Suspension | 275 mm DNM® Rebound / Compression Adjustable Shock | |
| Front Brake | Disc | |
| Rear Brake | Disc | |
| Front Wheel / Tire | Aluminum Alloy / Kenda® 60/100 - 14 | |
| Rear Wheel / Tire | Aluminum Alloy / Kenda® 80/100 - 12 | |
| Frame | Chromoly Steel Frame w/ Sub-frame | |
| Swingarm | Aluminum Alloy, "Straight" Type | |
| DIMENSIONS | ||
| Wheelbase | 48 inches | |
| Seat Height | 30.5 inches | |
| Ground Clearance | 10.5 inches | |
| Fuel Tank | 1.45 gallons | |
| Weight | 149 pounds | |
| L x W x H | 68 x 29.5 x 42 inches | |
| OTHER | ||
| Colors | Black, White | |
| Warranty | 30-day (Parts Only) Limited Warranty Coverage (learn more) | |
|
||
|
