| ENGINE | ||
| Engine Type | Inline 2-cylinder, 4-stroke, Liquid-cooled, DOHC | |
| Displacement | 698 cc | |
| Bore x Stroke | 83 mm x 64.5 mm | |
| Compression Ratio | 11.6 : 1 | |
| Maximum Power | 72.4 hp @ 8,750 rpm | |
| Maximum Torque | 48.6 ft·lb @ 6,250 rpm | |
| Fuel Supply | EFI | |
| Ignition | TLI | |
| Starter | Electric | |
| Transmission | 6-speed | |
| CHASSIS | ||
| Front Suspension | Telescopic, Inverted | |
| Front Travel | 4.5 inches | |
| Rear Suspension | Spring Pre-load and Rebound / Compression Shock | |
| Rear Travel | 2.3 inches | |
| Front Brake | Dual Disc Ø 320 mm, w/ ABS | |
| Rear Brake | Disc Ø 260 mm, w/ ABS | |
| Front Tire | 120 / 70 - ZR17 | |
| Rear Tire | 160 / 60 - ZR17 | |
| DIMENSIONS | ||
| Overall Length | 81.5 inches | |
| Overall Width | 30.1 inches | |
| Overall Height | 44.5 inches | |
| Seat Height | 31.1 inches | |
| Wheelbase | 55.5 inches | |
| Ground Clearance | 5.3 inches | |
| Fuel Tank | 4 gallons | |
| Weight | 432 pounds | |
| OTHER | ||
| Colors | Black, Red | |
| Warranty | 12-month / 12,000-mile Limited Warranty Coverage (learn more) | |
|
||
|
